Change Log:
Table of Contents
Introduction
When buying a high end replica watch, it’s important to consider both what’s on the outside and what’s on the inside. The factories in China have invested millions of dollars in re-producing exact copies of various Swiss watch movements. The accuracy of the replication varies, as does their reliability of these movements. In this guide I hope to be able to give you a basic understanding of which mechanical movements are good, which ones are ok, and which ones to avoid, and importantly, how to tell the various movements apart, since the information listed on Trusted Dealer (TD) websites in the descriptions isn’t terribly accurate.
Naming Conventions
Watch movements are often labeled with one or two letters followed by the Rolex movement number that they're a clone of. For example, the VS3235 is a clone of the Rolex 3235 movement. The prefix letters are important, but aren't assigned based on any consistent principals. Sometimes the letters are applied based on which watch factory exclusively uses the movement (e.g. VSF is the exclusive user of VS3235 movements, so that's where the "VS" part of the movement name comes from). But this pattern isn't universal, currently Clean Factory is the exclusive user of the new DD3285 movement, but that movement gets its DD prefix from "Dandong movement factory", the maker of the movement. In theory it would be best to use the movement factory names as the prefixes since movements like the VR3235 get the "VR" from the fact that they were initially used by the watch factory VRF, but are now used by many factories, so the VR3235 would be better named the SH3235 since it is made by the Shanghai movement factory. However, there are in fact two movement factories in Shanghai. Further complicating naming conventions is the fact that sometimes the letters "A" or "SA" are used as prefixes to simply mean "Asian" or "Super Asian". In conclusion:
The terms "Clone" gets thrown around rather loosely by factories, TDs, and this community. In the vain hope to bring order to the chaos, I've adopted the following convention within my own head cannon on what a "clone" means when it comes to movements. There are movements that fall between these levels, but I've found this way of thinking about movements to be useful. If you disagree, feel free to let me know.
40mm Submariner (1166XX and 114060) Movements
TLDR: The best option is the VS3135 or VS3130
For 40mm submariners (i.e. those with reference number 1166XX), there are six options in order of quality:
For reference here’s the genuine Rolex caliber 3135. Note how there is only one arm (the beat adjustor -- red arrow) on the balance bridge of the genuine movement. This is because the genuine movement has a “free sprung” balance. That means on the genuine movement the speed of the movement is regulated (i.e. adjusting how fast or slow the movement runs) by adjusting the moment of inertia of the balance wheel via tiny weighted screws on the rim of the wheel (green arrows). On all replica movements, regulation is done via a regulation arm that can be adjusted to lengthen or shorten the effective length of the hairspring. That’s why you see only one arm on the genuine movement, but two arms on the replica movements. Also note that the 3135 movement's rotor does NOT run on ball bearings (blue arrow).
VS3135 & VS3130
This is an excellent true clone movement. The part finishing quality and engraving is good. The hairspring mounted clockwise. This is the best clone of the Rolex 3135 movement. Note, there is a VS3130 version of this movement which is used on the no-date 40mm VSF subs (ref number 114060). The VS3130 is of equal quality to the VS3135, it is the best option for a no-date 40mm sub.
For identification against the genuine and other clone 3135 movements, note the position of the beat adjustor arm (red arrow) and the regulator arm (green arrow). Note the type and quality of the balance shock absorber setting (blue arrow). Note that there's a difference between the VS3135 used in VSF watches and the VS3135 used in CF watches: the version used in CF watches doesn't have a serial number engraved into the main plate.
This movement used to be exclusive to VS Factory (VSF), but is now widely available and replacements are available on eBay and AliExpress for around $130 USD.
VR3135 & VR3130
This is another good option for 40mm submariners. The part finishing and engraving is good. This is the second best clone of the 3135 movement. Note, there is a no-date version of the VR3135 called the VR3130. The VR3130 is a good quality no-date movement, second only to the VS3130. It's worth knowing that unlike the VS3135 (and gen) movement, the VR3135 doesn't have a shock setting for the escape wheel; this will reduce the shock resistance of the movement and is one of the reasons that the VS3135 is considered a better choice over the vr3135. Although the vr313x is a true clone movement and is part compatible with gen parts.
For identification of the VR3135 movement there is an easy way to tell it apart from the VS3135, on the VR3135 the hairspring is mounted counter-clockwise (purple arrow). The beat adjustor (red arrow) also has a black dot on it. But the regulator arm (green arrow) and the shock setting (blue arrow) look very similar to the vs3135.
Please note that there is a second version of the vr3135 which has a fake beat adjustor (blue arrow), and has the real beat adjustor (red arrow) and regulator arm (green arrow) pointing inwards. This is a style that is also seen in the VR3235 movement.
This movement is used in 40mm submariners from many replica watch factories. It is also available for purchase on eBay and AliExpress as a replacement for a broken movement for around $80 USD.
For anyone who wants a super deep dive into the Gen vs. Dandong (VS) vs. VR3135 movement, @steve_theonewatches did an amazing part by part macro photo comparison of the movements.
SH3135 & SH3130 (AR3130)
This movement has very low quality finishing. The hairpspring is mounted counter clockwise. Avoid this movement if possible. There is also a no-date version of this movement called the SH3130 (or sometimes the AR3130) which is of similarly poor quality. Avoid both the SH3135 and SH3130 (AR3130). This movement is a design clone and due to manufacturing tolerances differences with gen is not fully compatible with gen parts.
For identification purposes, not the style of the beat adjustor arm with the screw on the side (red arrow), the regulator arm (green arrow), and the style steel (not brass) cup for the shock setting (blue arrow).
SA3135 & SA3130
This movement has reasonable quality of part finishing, but poor quality engraving. The hairspring mounted clockwise. Go with the VR or VS movement if you have the choice or budget. There is a no-date version of this movement called the SA3130, which is of similar quality to the SA3135; as such a better choice for a no-date 40mm submariner is the VS3130 or VR3130. This is a design clone and it is not 100% compatible with gen parts.
For identification purposes note the round head on the beat adjustor arm (red arrow), the style of the regulator arm (green arrow), and the style and metal (steel) of the shock setting (blue arrow).
A2824
This isn’t a clone of a Rolex movement, rather it is an Asian clone of an ETA 2824 movement. There are quite a few variations on this movement since it has been around for decades and every movement factory in China has a clone version of it. This movement is reliable and easy to service and get replacement parts for. However, it doesn’t even remotely resemble what you’d find inside a Rolex. If you don’t care about what movement powers your rep, this isn’t a bad option. Complete Clone 2824 movements can be purchased on eBay and AliExpress for $20 to $50 USD. A genuine Swiss ETA 2824 will cost over $200 USD and will be a simple drop-in replacement for an Asian 2824.
There are some reps which come with this movement plus a decoration plate to make it look more like a 3135 movement. In general I would suggest either sticking with a stock 2824 movement and no decoration plate, or if you want a movement that looks genuine go for a rep with a vs3135 movement instead of a rep with an eta clone.
For identification purposes, note the position of the beat adjustor (red arrow), the regulator arm (dark green arrow), the fine tuning rate adjustor (light green arrow), the shock absorber (blue arrow, NB: there are many different styles of shock absorbers on different clones of the eta 2824, the one in the picture is a lower end one), and finally note that the rotor runs on ball bearings (orange arrow).
A2836
This is another clone of an ETA movement that is never found inside a real Rolex. This movement is also reliable and easy to service. Some people prefer these movements since they are easy to fix or replace and “nobody can see inside my rep submariner”... the functions at the crown i.e. the direction you have to twist to set the date / time, will not necessarily be the same as on a cloned movement. Also this is a strange choice for a movement in a submariner since it has the functionality for both a day and date function, so it is more often seen in reps of the Rolex DayDate.
For identification purposes, this movement looks the same as the 2824 from the balance side, so there really aren't any easy ways to differentiate the two without looking at the keyless works or dial side of the movement. The pic below is here more for reference and the coloured arrows point to the same features noted in the description of the 2824 above.
41mm Submariners (1266XX) and 36mm and 41mm Datejust
TLDR: The best movement is the VS3235 and VS3230(*)
There are several clones of the Rolex 3235 movement which appear in 41mm Subs, and 36mm & 41mm Datejusts. Please note: There are two version of the genuine Rolex 3235 movement which have slightly different sized date wheels. This is because the date window on the dial of the 41mm DJ is further out than the date window on the 41mm Submariner. If you are buying a replacement 3235 movement, be sure you get the correct version for your watch.
It’s worth noting that there are some 36mm Datejusts that use the VR3235 movement (e.g. the ones from Clean Factory), and the ones from VS Factory (VSF) use the excellent VS3235 movement. However, the majority of non CF or VSF 36mm DJs use an ETA clone. Unfortunately, the 3235 movement is too big for the 31mm Datejust case, so all replica 31mm Datejusts use lower end Asian clones of ETA movements. This is just a function of market pressure: there’s not a lot of demand for replica watches in lady sizes.
Genuine Rolex Caliber 3235
The genuine Rolex caliber 3235 is a relatively new movement with an astonishing 72 hour power reserve. Just like the genuine 3135 the genuine 3235 doesn’t have a regulation arm on the balance bridge (there is only a beat adjustor arm -- red arrow) since the movement is regulated by adjusting micro screw weights on the rim of the balance wheel (green arrows). All the replica 3235 movements have a regulation arm, so you’ll always see two arms on the rep movement balance bridges. Also note that the automatic rotor runs on ball bearings (blue arrow). Furthermore, the escape wheel on the gen movement is skeletonized (orange arrow), whereas it is solid on all the replicas of this movement.
VS3235 / VS3220
This is an incredible movement that is currently only available in VS Factory (VSF) subs and DJs. The movement has an amazing 70+ hour power reserve and is a true clone, so it is part compatible with the genuine Rolex movement. This means that it’s possible to swap gen parts into this movement to improve it. A common part swap on this movement is to replace the balance complete, pallet fork, and escape wheel with gen parts. With those parts swapped, the movement is virtually indistinguishable from the genuine caliber.
For identifications of this movement, look at the position of the two arms coming off the balance bridge (beat adjustor -- red arrow, and regulator arm -- green arrow): on the VS movement they face outwards. Also note the paraflex shock setting spring (blue arrow). The paraflex shock setting on the VS3235 movement is the actual functional shock setting, unlike on the VR3235 where the paraflex shock setting is simply a decoration plate. Note the direction that the hairspring is mounted: the hairspring starts at the beat adjustor and winds clockwise through the regulator arm and inwards to the balance staff. There's a new version of the VR3235 movement which looks similar but it has the hairspring mounted counter clockwise. Be careful, reps with a VS3235 movement are generally more expensive than reps with a VR3235 movement, be sure you get what you're paying for (see info on VR3235 below).
In Spring 2024 a 3230 "no date" version of this movement was officially released by Dandong. This movement can now be found in reps from VSF such as their Oyster Perpetuals, Airking, and Explorer 1. Many of these reps were sold before the new vs3230 was available, and were sold with a vs3235 which had a phantom date position when you pulled out the crown. There is a mod that allows for the removal of the phantom date correction crown position from the VS3235 and convert it into a true 3230 clone (i.e. only two crown positions: winding and time setting). For identification of the VS3230 see the pic below: The beat adjustor (red arrow), the regulator (green arrow), the direction of the hairspring (orrange arrow), and the 3230 engraving (blue arrow).
Also note that is is not possible to buy this movement on eBay or AliExpress. However, if you have a VSF sub or DJ with a broken movement, there are many rep-friendly watch smiths who will be happy to swap in a VR3235 movement for you and take the broken VS3235 off your hands for spare parts.
VR3235 / VR3230
This is a very common movement that is used in Subs and DJs from many different factories. This movement is technically not a clone but more of a hybrid between a 3135 and 3235 movement, as such I consider this to be an "homage clone". This movement is reliable, although it doesn’t have the same power reserve of the VS3235, at only around 40 hours. While spare parts for this movement can be hard to find, a replacement movement is only around $100 USD on AliExpress, so it’s often more economical to replace the movement with a new one rather than service an old one.
This movement used to be easy to identify (see below for info about the VR3235 v2) because it has a “fake” beat adjuster arm pointing outwards from the balance bridge (blue arrow), but the two functional arms (beat adjustor -- red arrow, and regulator arm -- green arrow) are hidden underneath the balance bridge and face inwards. Also of note, the end-shake adjustment screw on the balance bridge (purple arrow) isn’t functional, so adjusting the end-shake of the balance needs to be done with foil shims. The end shake adjustment screw simply secures a decoration plate that houses the fake paraflex shock setting (orange arrow), there is a real shock setting under this decoration plate.
Note: there is a no-date version of this movement called the VR3230 which is used on Clean Factory (CF) no-date 41mm submariners (as of August 2022). The VR3230 is a good option for a clone movement in a no-date 41mm submariner, however a VSF no-date 41mm submariner with the VS3235 modded to be a VS3230 is a better option.
In spring 2024 we started seeing a new version of the VR3235 and VR3230. This new version did away with the decoration plate on top of the balance bridge and the fake hairspring stud / beat adjustor that used to face outwards (blue arrow above). The new "v2" version of the VR3235 and VR3230 now have outwards facing beat adjustor and regulator arms. This makes the VR3235 look very similar to the VS3235, but they are different in one important way: the direction in which the hairspring is wound. The VR hairspring is wound counter-clockwise, the VS hairspring is wound clockwise. The picture below is of a VR3235, the hairspring starts at the beat adjustor (red arrow), and goes through the regulator (green arrow), and winds inwards in a counter clockwise direction (orange arrow).
SA3235
This movement appears in some DJ41s and DJ36s. This is not a great movement, and should be avoided. The movement is decorated with poor quality plates. In the images it’s possible to see paint flaking off of the “reversing wheels” of the automatic model.
This movement can easily be identified by the decoration at the center of the rotor that is trying to make it look like the rotor runs on ball bearings like the gen 3235 (red arrow). Furthermore, the shock setting spring (blue arrow) on the balance bridge is a three sided closed spring vs. the paraflex springs that are present on the gen, VS and VR (although on the VR the paraflex spring is part of a decoration plate, and the real shock setting can be found underneath). This is a movement to avoid.
GMT Movements
TLDR: The best GMT movement is the DD3285
For GMT movements, there are movements that have the correct hand stack (CHS) and incorrect hand stack (ICHS) on modern (6-digit) GMT models (1167XX, and 1267XX). Correct hand stack means that the hour hand is on the bottom, the GMT hand is next, then the minute hand, and the seconds hand is on top. Incorrect Hand Stack means that the GMT hand is on the bottom, the hour hand is on top of the GMT hand, then the minute hand, and the seconds hand on top.
Details on each movement are provided below, but this graphic (by @KJ2020) is a shortcut to helping ID each of the 318X series movements movements. Note: There are two "true" 3285 clone movements which are (as of summer 2023) starting to see widespread adoption by rep factories. With these two new 3285 movements (see bottom of the GMT movement section) hopefully the days of trying to figure out exactly which GMT movement is the watch you're buying (to avoid the time-bomb movements) will be a thing of the past.
Hat tip to RWI's Gandalf the Grey of GMT movements: @KJ2020 who helped me correctly identify each of the myriad clone GMT movements -- Thank you for helping me get this right.
VR3186 (Correct Hand Stack)
This is a good movement. The VR3186 is reliable and has an hour hand jumping mechanism is strong. This movement is basically a true clone, except the hour hand jumping mechanism is not the same as gen (it's a better more reliable design IMO), so other than the hour hand jumping mechanism this movement can accept gen parts. The VR3186 is sometimes engraved with the number 3285 (black arrow), but it’s the same movement. Be careful if you are trying to order a replacement SH3285 movement from eBay or AliExpress, the SH3285 is sometimes called a VR3285, but if you search for "VR3285" on AliExpress you'll often find a VR3186 movements with "3285" engraved them. You can not put a VR3186 into a case designed for an SH3285. If you need a replacement SH3285 order it from a TD not from AliExpress.
Below are two pictures showing the VR3186 movement with different engraving. Note that this movement is easily identifiable by the position of the arms on the balance bridge: both the beat adjuster (red arrow) and regulator arm (green arrow) point inwards and there’s a fake beat adjuster arm (blue arrow) facing outwards. Also note that a true 3285 clone movement (see below) has a rotor that runs on ball bearings not a jewel pivot (purple arrow) and has a paraflex shock setting (orange arrow) not a kif shock setting.
Note that there are VR3186 movements which have been engraved with the numbers "3285" (black arrow) but they are VR3186 in every other way.
Also note that there is an older version of the VR3186 (sometimes called the VR3185 or VR3186 v1) which has the beat adjustor arm and regulator arm facing outwards. This version of the movement can be identified by inspecting the balance bridge: the beat adjustor which has the hairspring screw pointing out the end of the arm (red arrow) and regulator arm (green arrow) point outwards (unlike the newer VR3186). Also, the shock setting has a brass cup (blue arrow).
For anyone interested in a deep dive, @CTime has prepared a part by part comparison of the VR3186 against the gen.
SH3186 (Correct Hand Stack)
This is a time-bomb movement that should be avoided. The hour hand jumping mechanism is weak on this movement and is prone to breaking. Furthermore, the hour hand jumping mechanism isn’t gen-spec, so it can’t be repaired with gen parts. This movement can be identified again by the position of the beat adjustor arm (red arrow, note the position of the hairspring screw on the side of the beat adjustor arm unlike on the old version of the VR3186 where this screw is on the end of the arm), and the regulator arm (green arrow) on the balance bridge. Also, unlike the old version of the VR3186, the SH3186 has a steel cup for the balance bridge shock setting (blue arrow).
SA3186 (Correct Hand Stack)
This is another time-bomb movement. Like the SH3186 this movement has a weak hour hand jumping mechanism and should be avoided. This movement is easy to identify because unlike all the other CHS GMT movement it has its hairspring mounted clockwise -- this means that the beat adjustor (red arrow), and regulator (green arrow) are reversed compared to the VR3186 and the SH3186. Also, the shock setting of this movement has a steel cup (blue arrow).
SA3285 (Correct Hand Stack)
In 2020, GMF released a movement called the SA3285 which was basically a slightly different version of the SA3186. This movement can be identified by the beat adjustor arm (red arrow), regulator arm (green arrow), and shock setting (orange arrow) that are the same as the SA3186. However, the SA3285 had holes drilled around the rotor mounting (blew arrow) to make it look like the rotor was running on ball bearings like a true 3285 movement (see below). This movement is of similar inferior quality as the SA3186, so it should be avoided.
A3186 (Incorrect Hand Stack)
This isn’t a clone of a rolex movement, but rather a clone of an ETA movement that is decorated to look like a rolex movement. ETA GMT movements are reliable and inexpensive to service and repair, however, the functionality does not match the Rolex GMT calibers. A better option is the VR3186. The movement is easy to identify by the shock setting (red arrow), the ETA style winding works (green arrow), and the ETA style reversing wheels (blue arrow).
A2836 (Incorrect Hand Stack)
It’s unclear why this movement is labeled as an Asian clone of the ETA 2836, since the ETA 2836 is not a GMT movement. It’s more likely that this is a clone of the ETA 2893 movement. Nonetheless, this movement is not going to function like a genuine Rolex GMT movement, and has the wrong hand stack on the dial. A far better option is to go with the VR3186. This movement is easy to identify from the ETA style balance cock assembly (red arrow).
SH3285 aka VR3285 (Correct Hand Stack)
This is a new movement (as of March 2023) which has started to appear in C+ Factory GMTs and Explorer IIs. @CTime posted an excellent photo comparison of the SH3285 with the DD3285 and the Gen 3285. This movement is closer to gen spec than the VR3235 movement (discussed above), and is compatible with gen pars in some areas (e.g. the keyless works), but the balance, pallet fork, and escape wheel are all not gen-spec. As such I would classify this movement as an "homage" level clone.
There have been some reliability issues reported with the SH3285 movement. Furthermore, the SH3285 appears to have subtly different sized / position parts compared to both the VR3235 movement (with which it shares its train wheel and escapement design), and the gen/DD3285.
The SH3285 can be easily identified by the position of the beat adjustor (red arrow) and regulator arm (green arrow) which face inwards and the fake beat adjustor arm (blue arrow) which faces outwards. Additionally, the end-shake adjustor screw (purple arrow) is not functional, but simply secures a decoration plate which contains a fake paraflex shock setting (orange arrow). Also, unlike the 3186 movement, the SH3285 movement's rotor runs on ball bearings (pink arrow).
Note, in November 2024 we saw the release of a new updated version of the SH3285 in the QF Explorer 2 (but it's safe to assume this update will soon be seen in all GMS and Explorer 2s made by factories that previously used the older version of the SH3285). Like the updates to all the other Shanghai movements which we first saw in the summer of 2024, the update to the SH3285 gets rid of the fake shock setting on the balance bridge and moves the beat adjustor (Red arrow), and regulator (green arrow) to point outwards like we've traditionally seen on Dandong movements. However, it's still possible to easily distinguish a DD from an SH movement by looking at the chirality (direction of the coil) of the hairspring) -- the hairsprings on Shanghai movements (including the SH3285-2) coil inwards in an anti-clockwise direction (blue arrow), on a DD movement that hairspring coils clockwise.
DD3285 aka CF3285 (Correct Hand Stack)
This is a new movement from Dandong movement factory (one of the best rep movement factories in China). This movement will apparently be exclusive to Clean Factory (CF). Based on the photo comparison posted above by @CTime, the DD3285 appears to be based on the excellent VS3235 movement, so it is likely that it will have the long 70 hour power reserve. This movement is a true clone and is compatible with gen parts.
This movement can be easily distinguished from the SH3285 above by the position of the beat adjustor arm (red arrow), and regulator arm (green arrow) which both point outwards and are very similar to the VS3235 movement from which the DD3285 is based. Also note the functional paraflex shock setting (purple arrow) and that the rotor runs on ball bearings (blue arrow) unlike clones of the 3186 movement.
DayDate Movements
Prior to September 2023, the only movement available for DayDate movements was the asian clone of the ETA 2836 movement (see above for images of the clone ETA 2824 movement since the 2836 looks the same from the balance side). The ETA clone is reliable and easy to service, however it doesn't operate in the same way as the gen 3255 movement from the crown. As such, for those looking for a closer to gen rep, there has always been a desire for a clone 3255 movement. This wish appears to have been granted in the form of a 3255 clone movement that looks like it is based on the reliable (albeit not a true clone) VR3235 movement from Shanghai movement factory.
VR3255
This movement is new as of September 2023 and has appeared in DayDates from EWF and ARF . The movement looks like it comes from Shanghai movement factory and appears very similar to the SH3285 (GMT) movement and the VR3235 movement. All of these movements share the same inward facing beat adjustor arm (green arrow) and regulator arm (red arrow), with a fake hairspring stud pointing outwards (blue arrow). This movement also appears to have the same non-functional balance end-shake adjustor (magenta arrow) which doesn't adjust end-shake, but rather simply secures the decoration plate on top of the balance bridge. The movement is identifiable by the 3255 engraving (black arrow). As of this update (January 2024), there is no information about the reliability of this movement, but we should expect that like most new movements (e.g. the SH3285) it will take a few iterations to work out the bugs.
Daytona Movements
TLDR: The DD4130 is the best Daytona movement
There are two clone 4130 movements: the original Dandong 4130 movement used by Noob (until Noob was shut down in a raid in 2021), and now used by CF, BTF, QF, and "new Noob". But in June 2023 Shanghai Movement factory released a version of the 4130 movement (called the SH4130). In January 2024 we saw the introduction of the SH4131 from Shanghai movement factory, and a decorated "4131" in a 126500 Daytona from ARF. These movements are discussed below.
Dandong 4130 (aka DD4130 or "Noob 4130")
This movement is also known as the Noob4130 / N4130 / Dandong 4130. They are all the same. This movement is one of the highest quality replica movements available. For a long time it was exclusively available to Noob Factory. When Noob was raided and shut down in 2021, this movement disappeared from the rep scene. However, in early 2022 Clean Factory (CF), and then Better Factory (BTF), and Q Factory (QF) started making Daytonas with this movement. Daytonas with this movement are more expensive than Daytonas with a 7750 movement. However, if you care about the reliability and longevity of your rep, go for the DD4130. It’s worth the extra cost.
The DD4130 movement is a true clone and is also compatible with genuine Rolex parts. It’s common to replace the balance-complete, and the chronograph seconds wheel to build a movement that is nearly indistinguishable from the genuine Rolex caliber 4130. For anyone interested in a part by part macro photo comparison between the gen and Dandong 4130 movement, @CTime did the heavy lifting for you.
The DD4130 looks completely different from the 7750, learn to tell the two apart so that you can validate any claims made by a seller. Easy parts to look for when identifying a DD4130 vs. a 7750 are that the DD4130 has three screws securing the rotor (green arrow), a column wheel (red arrow), and a balance bridge (blue arrow) rather than a balance cock.
Skeletonized Dandong 4130
There is a version of the Dandong 4130 which has been skeletonized and is used in several special editions of the Daytona which are produced by SONIC Factory in China. The Skeletonized version of the DD4130 is easily identifiable as a derivative of the Dandong 4130 movement due to the position of the beat adjustor (red arrow) and regulator (green arrow) arms on the balance bridge. In addition, the skeletonized version of this movement has many parts of the bridges and rotor which have been hollowed out (blue arrows). While this is an interesting and unique movement, the level of finishing isn't the same as the "gen" version which is customized by Artisans De Geneve. Nonetheless, this is an excellent movement and a beautiful piece for any dedicated Daytona rep collector.
Shanghai 4130
In June 2023 Shanghai Movement factory released a 4130 clone movement. As of January 2024 there is no long term reliability information about the SH4130 but there were some initial issues with chronograph hands not resetting properly. This movement is mostly a true clone, although the balance bridge, pallet fork, and escape wheel are not gen spec (it's possible that other parts are non-gen spec too).
There is an easy way to differentiate the SH4130 from the DD4130: The position and style of the beat and regulator arms on the balance bridge. Unlike the DD4130 where the beat and regulator arms point outwards, on the SH4130 the beat adjustor (red arrow) and regulator (green arrow) point inwards. Furthermore, on the SH4130 there is a fake hairspring stud (blue arrow). This style of balance bridge is common on other Shanghai clone movements such as the VR3135, VR3186, and SH/VR3285.
AR4131 (Actually a decorated SL-4801 movement)
At the end of December 2023, we saw the release of a 126500 Daytona from AR+F which uses a new "4131" movement. This 4131 movement appears to be based on a Peacock SL-4801 movement (the Dandong clone of the 4130 that's different enough for Dandong to sell officially). Visible are the beat adjustor (red arrow) and regulator (green arrow) arms. This version of the movement has been engraved with the "4131" caliber number (blue arrow). And it has a different rotor that has two large cutouts (purple arrow). However, it doesn't have an updated shock setting (yellow arrow) -- the gen 4131 uses the new paraflex shock spring rather than the older incabloc style spring. However, there are some mechanical updates to this movement which show that it's not simply a redecorated 4130. There are three visible changes in the AR4131 from the DD4130: 1) The column wheel is different (black arrow), 2) the vertical clutch jaws and spring is different (cyan arrow), and 3) the hammer spring has been peened (orange arrow). Additionally, thanks to the initial movement tear down by @CTime we know that the rotor only winds the mainspring in one direction (so the rotor will spin freely / loudly in the other direction). A complete teardown of the movement is also available. This does not appear to be a "true clone" 4131 but rather a medium effort attempt at making an inexpensive off the shelf chronograph movement look like a 4131. As of January 2024, I would recommend waiting until there are other 4131 movements options available.
There is also a skeletonized version of Peacock chronograph movement called the SL-4802. The SL-4802 has appeared in 12-series Daytonas from So Boring Factory (SBF). NB: SBF is a sub-factory of VSF, so you may see the SL-4802 movement in a "VSF Daytona"... Also, VSF / SBF have labeled this movement as the "DD4131", let's just put a stop to that right now. Technically Peacock (the makers of the SL-4801 and SL-4802) is based in Dandong, so the "DD" prefix isn't an outright lie. But calling an SL-4801/2 movement a "4131" is an outright lie. TDs if you're reading this, please don't participate in this nonesense. The movement in the ARF Daytona is a "decorated SL-4801", and the movement in the VSF/SBF Daytona is a "Peacock SL4802" or a "Dandong 4802", but it is NOT a DD4131.
The SL-4802 is easy to identify, it's an undecorated skeletonized version of the SL-4801. The rotor is secured by a single screw (red arrow) not three screws like on a real 4130 or 4131. It also has outward facing beat adjustor (green arrow) and regulator (cyan arrow), and is skeletonized. The SL-4801/2 movements aren't bad... they are a good option for a lower cost Daytona rep. They are thin (unlike the 7750 movement, see below), and they are functionally very similar to the 4130 on which they are based. The movement is reasonably inexpensive, so it's possible to buy replacements and access spare parts if something goes wrong. However, the SL-4801/2 rotor only winds in one direction which means it will be noisy as it spins freely in the other direction -- something to keep in mind if rotor noise bothers you.
SH4131
In late January 2024 it was announced that Clean Factory had collaborated with Shanghai movement factory to produce an SH4131 movement that would be exclusive to Clean. This movement has some interesting features... note the updated engraving (purple arrow), and the familiar SH-style fake hairspring stud on the balance bridge (blue arrow) with the regulator arm pointing inwards (red arrow). Also of note is that unlike many reps, the rotor bearing block on this movement is completely filled with ball bearings (orange arrow) -- this should make the rotor run more smoothly (and more quietly). @CTime has posted an excellent part by part comparison of the SH4131 with a gen 4131. From The part by part comparison it appears that the SH4131 is basically a true clone except of the escapement (balance, pallet fork, and escape wheel).
In spring 2024 there was an updated version of the SH4130, SH4131, and SH4132 which were all released with a slightly updated balance bridge that featured outwards facing beat adjustor and regulator arms (like the DD versions of the 413X movements). So identifying the SH vs DD versions of Daytona movements has become more difficult. However, just like the updates to the VR3235 which ditched the balance bridge decoration plate, there's still a way to identify the SH versions from the DD versions: the SH versions have the hairpsring winding counter clockwise, whereas the DD versions have the hairspring winding clockwise. Below is an SH4132 v2 wher you can see the beat adjustor (red arrow) where the hairspring starts, and then winds counter clockwise (orange arrow) through the regulator (green arrow) and spirals inwards to the balance staff.
SH4132
The SH4132 is a slightly differently decorated version of the SH4131 that can at present (May 2024) be found in the new Q Factory (QF) Daytona Le Mans. This movement is identical to the SH4131 except that it has "4132" engraved on it (red arrow) and it has a gold coloured rotor (green arrow) instead of the silver coloured one found on the standard SH4131. This movement features the same fake paraflex shock setting (cyan arrow) decoration plate (purple arrows) on the balance bridge that is found on the SH4131. This makes the real underlying balance bridge shock setting a pain in the ass to service because the decoration plate is secured with two screws from the under side of the balance. This movement (and the SH4131) also don't have escape wheel shock settings, but that's not a serious drawback since the escape wheel is extremely light and unlikely to damage its pivots in a hard knock. Note: there is now a v2 of this movement that drops the fake hairspring stud and has outwards facing beat and regulator arms. But remember SH movements have a hairspring that coils counter clockwise, DD movements have a hairspring that coils clockwise.
DD4131
The Dandong 4131 is a new movement (as of May 2024) that has first appeared in the Better Factory (BTF) 12-series Daytonas. This movement has the outward facing beat adjustor (green arrow) and regulator (red arrow) that we typically see on Dandong movements. Also note that like all Dandong movements, the hairspring on this movement is mounted clockwise (orange arrow). The DD4131 also features a completely full ball bearing race to support the rotor (not pictured). Hopefully this movement will be a worthy successor to the DD4130 which has served so well in the 11-series Daytonas. We can see from the pictures that this movement features a gen-like skeletonized escape wheel (blue arrow). It has also been confirmed that this movement (unlike the SH4131) features the gen-like chronenergy geometry of the pallet fork. It's possible (not yet confirmed) that the DD4131 will be able to support a gen balance complete swap, whereas the SH4131 is not compatible with a gen 4131 balance -- this is something to keep in mind for anybody planning a 12-series Daytona franken build.
7750
This is an Asian clone of an ETA 7750 movement. The reason that this movement isn’t great for the Daytona is because it is thicker than the 4130 movement, so the movement is often slimmed down (and thus made less reliable) to fit inside a 12.4mm thick Daytona case. Furthermore, the Daytona has its small seconds at 6 o’clock, but this is not the default position for the small seconds complication on the 7750 movement; various additional wheels need to be added to the top of the 7750 movement to get everything into the correct position. This complication adds stress to the movement and reduces reliability. With the clone 4130 widely available, it's a good idea to avoid Daytonas with the 7750 movement.
The 7750 can be identified by the single screw securing the rotor (red arrow), and the balance cock (green arrow) vs. the balance bridge see on the 4130.
- August 25th 2022 - Initial version published on r/RepTime
- March 9th 2023 - Updated version published on RWI. Updated to include information about the new SH3285 found in C+ Factory GMTs and DD3285 found in Clean Factory GMTs.
- March 14th 2023 - Update to include a link to Steve's amazing 3135 photographic comparison, and to correct images in the 3135 section. And to add a collage of the different 318X GMT movements (thank you @KJ2020 for this). And added a reference to @CTime photo comparison thread between gen and Dandong 4130 movements.
- March 15th 2023 - Added link to CTime's macro picture part by part comparison of vr3186 to gen.
- June 28th 2023 - Updated to include the new Shanghai 4130 Daytona movement, and to include some additional reliability information about the Shanghai 3285 GMT movement.
- July 26th 2023 - Fixed broken images. No information updates.
- September 24th 2023 - Added a section about the new VR3255 DayDate clone movement. And Added a section about the naming conventions of rep rolex movements.
- December 28th 2023 - Added info about the mod that converts a VS3235 into a 3230 movement (i.e. the phantom date fix mod).
- January 12th 2024 - Added information about the new "4131" Daytona movement from AR+F, and the skeletonized 4130 movement from SONIC Factory.
- January 15th 2024 - Corrected some information about the new
DandongShanghai 4131 movement used in the AR+F 126500 Daytonas. - January 22nd 2024 - Updated the information about the new 4131 movement found in AR+F 126500 Daytonas.
- January 27th 2024 - Linked to thread on AR+F 4131 movement tear down. Added section about what is and isn't a "clone" movement.
- January 29th 2024 - Updated to include the new Shanghai 4131 Daytona movement. Added information to each of the movement sections about what level of "clone" the movement is relative to gen (see definitions for True / Design / Homage / Decoration. I also added a table of contents and increased the font size of the headings to make things easier to read (this article is getting long). I also added a TLDR section at the top of each movement section about which movement (in my opinion) is the best option.
- May 28th 2024 - Updated to include information about the SH4132 and DD4131 movements. I also expended the section on the SL-4801 to include info about the SL-4802 which is found in the SBF Daytonas.
- July 29th 2024 - Updated to include information about the new versions of the VR3235, VR3230, VR3255, and SH4131 movements which don't have the fake beat adjustor on the balance bridge anymore. These movements look VERY similar to the Dandong versions. Identifying movements just became a LOT harder, but there is an easy way to tell an SH/VR movement from a DD movement: The hairspring on SH/VR movements is mounted counter clockwise, whereas it is mounted clockwise on DD movements.
- November 1st 2024 - Updated to include a picture of the new version of the SH/VR3285 movement (the "SH3285-2") which, like the Shanghai movements which were identified as being updated on July 29th 2024, this updated version has the outward facing beat adjustor and regulator arms and a counter-clockwise curving hairspring.
