NEW RELEASE: VSF 3235 -> 3230 Phantom Date Fix Mod

dogwood

I'm Pretty Popular
Patron
Section Moderator
Certified
7/9/21
2,516
5,721
113
Canada
I have several watches with VS and VR movements and have never noticed a spacer between the movement and the rotor. Is this usual? I ask because my Clean DJ has a rather flimsy rotor that, with even slight pressure, already scrapes against the automatic bridge when using Rodico. Could it be that the spacer was forgotten? Many thanks in advance!
The spacer washer isn't there all the time. I suspect it's included only when the rotor is found to touch the bridges when it spins. Since the rotor bearing block is press fitted into the rotor, there will be a certain amount of variability between different rotors in terms of where the rotor sits relative to the rotation plane of the ball bearings. Rather than tightening the tolerance for the height of the bearing block within the rotor (as I assume gen Rolex rotors are made), I assume that both Shanghai and Dandong simply have an optional spacer washer that can be installed during assembly to ensure that the rotor clears the bridges by a certain distance.


Drache1510

Getting To Know The Place
4/11/24
16
2
3
The spacer washer isn't there all the time. I suspect it's included only when the rotor is found to touch the bridges when it spins. Since the rotor bearing block is press fitted into the rotor, there will be a certain amount of variability between different rotors in terms of where the rotor sits relative to the rotation plane of the ball bearings. Rather than tightening the tolerance for the height of the bearing block within the rotor (as I assume gen Rolex rotors are made), I assume that both Shanghai and Dandong simply have an optional spacer washer that can be installed during assembly to ensure that the rotor clears the bridges by a certain distance.
Thank you for your response. I'm considering installing such a spacer if I can find one online.
